Spectrum Digital, Inc
1.1 Key Features
The DM355 EVM is a standalone development platform that enables users to
evaluate and develop applications for the TMS320DM355 processor. Schematics,
logic equations and application notes are available to ease hardware development and
reduce time to market.
HP OUT
Battery
ENET
RJ45
DM9000A
IR
MSP430
JTAG
MSP430
Reset
LINE OUT
LINE IN
AIC33
Codec
MAC/PHY
I 2 C Bus
EMIF
LEDs
MIC OUT
DC6
SPI
ROM
DC3
NAND
SW6
1
2
1
2 3
SW7
4
Switches
SD/MMC
Connectors
SD0 on Bottom
McBSPs
SD/MMC
USB
DM355
16
DC7
DDR2
3.3V I/O Supply
1.8V Supply
USB 2.0
DC5
UART0
Video In
Mux
1.2V Core Supply
JTAG
Video Out
Video
Decoder
TVP5146
PWR
20 Pin ARM JTAG
RS-232
14 Pin TI JTAG
Figure 1-1, Block Diagram DM355 EVM
The EVM comes with a full complement of on board devices that suit a wide variety of
application environments. Key features include:
? A Texas Instruments DM355 processor with an ARM processor operating up to
216 Mhz.
? 1 video input port, supports composite or S video
? 1 composite video DAC output
? 128 Mbytes of DDR2 DRAM
? UART, 2 SD/MMC card interfaces or 1 SD/MMC and 1 CE-ATA Disk Drive Interface
? 2 Gigabytes NAND Flash
? AIC33 stereo codec
? USB2 Interface
1-2
DM355 EVM Technical Reference
